Product overview
GEORAD CS1500 is compact and versatile for deeper surveys. Designed for thick structures with a 1500 MHz antenna, it detects rebar, pipes, cracks and voids up to 1.5 m in concrete with ORION™.
1500 MHz antenna
Greater penetration
ORION™ software
2D/3D real-time analysis
Quick Scan mode
For extensive surveys
Firmware updates
Free
Design
Ergonomic
Warranty
Extendable up to 5 years
Training
Included free of charge
External auxiliary battery
Long-lasting, included
Technical specifications
Full details and technical characteristics of GEORAD CS1500
Antenna configuration
1500 MHz
shielded and compact
up to 1 mm
Performance
up to 1.5 m
up to 2.1 m
real time (ORION™)
Physical characteristics
14 × 19 × 8 cm
≈ 0.8 kg
IP 52
−5 °C … +40 °C
Data processing
CAD/GIS compatible
2D/3D in real time (ORION™)
Quick Scan for extensive surveys
touch display + USB
Power system
rechargeable NiMH battery pack – up to 8 h
included
1.5 h (internal) / 4.5 h (external)
Image gallery
Accessories and equipment
Included accessories
